Water pump/oil pumpIntroduction
This scheme adopts the single resistor FOC algorithm, which has a simple circuit and low cost; Through self-developed sensorless FOC algorithm, power closed-loop and speed closed-loop, it has the advantages of smooth motor control, low operating noise, and strong load starting ability
Features the Solution
● Hardware composition: ADM16F03A2Q+MOSFET
● Motor speed: 4000 rpm
● Operating voltage: DC12V
● Power: 40-400W
● Multiple protection measures: overcurrent, short circuit, overvoltage/undervoltage, locked rotor, phase loss, power, startup protection, etc.
● Motor speed: 4000 rpm
● Operating voltage: DC12V
● Power: 40-400W
● Multiple protection measures: overcurrent, short circuit, overvoltage/undervoltage, locked rotor, phase loss, power, startup protection, etc.
